Linhai has combined products from around the world to create a new standard in utility vehicles designed for work. Designed in France, the 800-Diesel is Linhai's latest UTV for 2015. This work horse UTV is powered by the Japanese 3 cylinder Perkins 403D engine coupled to a CVT dual range transmission made by CVTech in Canada. Producing maximium torque at just 2000 rpm allows this UTV to tow & carry up to 1400kgs, by adding diesel tractor power and with the speed and capabilities of a UTV, it can take all your equipment to your work site, quickly, safely and with ease. This UTV is truely two vehicles in one ! Linhai 800-Diesel is one of the SAFEST on the market, with Australian Approved ROPS, 5 stud 14 inch steel wheels and decent assist drive system. This Linhai UTV has been designed for WORK SAFE approval. Ideal Farm Ute
800cc DIESEL 4wD Farm UTV Side by Side
Engine Type 3 Cylinder, In Line, Water Cooled Diesel
Engine Model Perkins 403D-07Cooling Liquid
Bore x Stroke 67mm x 72mm
Displacement 762cc
Compression Ratio 23.5:1
Maximum Torque 44.5 N.m @ 2000 rpm
Starter System Electric
Battery ⁄ AMP Hour 12 Volt 45 Ah
Lubrication System Forced FeedIgnition CDI
Transmission CVT High ⁄ Low ⁄ Neutral ⁄ Reverse, 2WD ⁄ 4WD,front & rear diff lock, Downhill Assist
Clutch Constant Variable Transmission (CVT)
Final Drive Shaft Drive
Gearshift Mode Lever Hi ⁄ Low
Front Brakes Dual Hydraulic Disc
Rear Brakes Hydraulic DiscParking Brake Hand
Steering Adjustable Tilt Steering Wheel
Front Suspension Dual A-Arm coil Over Shock
Rear Suspension IRS Dual A-Arm coil Over Shock
Front Tyres 26 x 9 x 14
Rear Tyres 26 x 11 x 14
Wheels Steel - 5 stud
Length 3,018 mm
Width 1,520 mm
Height 1,905 mm
Wheelbase 1,930 mm
Distrance Between Front Wheels 990 mm
Distance Between Rear Wheels 990 mm
Ground Clearance 280 mm
Dry Weight 700 kg
Fuel Capacity 35 litres
Cargo Box Capacity 400 kg
Towing Capacity 680 kg
Available in White, Red, Green or Yellow
